Digital Panel Meter Enclosure
/
Non-standard
Product code: 3010
[ Print version ]
[ Return ]
Size: 330x102x58 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Basic install(Assembly parts list):
Serial No.
Part No.
Part Name
Qty
Material
Surface Finish
Remarks
1
3010-1
Top Cover
1
ABS
Mill Finish
2
3010-2
Base
1
ABS
Mill Finish
3
Optional Parts
Serial No.
Part No.
Part Name
Qty
Material
Surface Finish
Remarks
1
2
