Digital Panel Meter Enclosure
/
48x48
Product code: 4853
[ Print version ]
[ Return ]
Size: 48x48x80 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
4853
1
ABS
2
4816
1
ABS
3
4804
1
ABS
4
4813
1
ABS
5
Optional accessories
No.
Part No.
Part Name
Qty
Material
Note
1
14-12
1
ABS
2
14-13
1
ABS
3
14-14
1
ABS
4
14-15
1
ABS
5
4803
1
ABS
6
4805
1
ABS
7
