Metal Enclosure
/
Iron Cabinet
Product code: 16-68
[ Print version ]
[ Return ]
Size: 275x220x100 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
16-68-1
1
Iron
2
16-68-2
1
Iron
3
16-68-3
1
Iron
4
suo403
1
Iron
5
[ Print version ]
[ Return ]
