Plastic Enclosure
/
Frequency Transducer Enclosure
Product code: 26-69
[ Print version ]
[ Return ]
Size: 310x165x189 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
26-69-1
1
ABS
2
26-69-2
1
ABS
3
26-69-3
1
ABS
4
26-69-4
1
ABS
5
26-69-5
1
ABS
6
26-69-6
1
Iron
7
26-69-7
2
Iron
8
26-69-8
1
Iron
9
