Plastic Enclosure
/
Hand-held Enclosure
Product code: 21-94D
[ Print version ]
[ Return ]
Size: 172x120x61 mm
ProtectionClass: no
Battery: no
Windows: 3.2",70x40mm
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
21-94D-1
1
ABS
2
21-94D-2
1
ABS
3
21-94D-3
1
ABS
4
[ Print version ]
[ Return ]
