Plastic Enclosure
/
Electric Conjunction Enclosure
Product code: 20-19
[ Print version ]
[ Return ]
Old code: PC19
Size: 193x104x63 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Assembly Parts List
Serial No.
Part No.
Part Name
Qty
Material
Surface Finish
Remarks
1
PC19-1
Top Cover
1
ABS
Texture Finish
2
PC19-2
Base Part
1
ABS
Texture Finish
3
PC2-1-01
Big Cover
1
ABS
Texture Finish
4
PC2-1-02
Small Cover
1
ABS
Texture Finish
5
M3x10 Tap Screw
6
Iron
6
Optional parts
Serial No.
Part No.
Part Name
Qty
Material
Surface Finish
Remarks
1
2
