Plastic Enclosure
/
Wall-mounting Enclosure
Product code: 19-17
[ Print version ]
[ Return ]
Old code: 1050-3
Size: 160x110x67 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
19-18-3
1
ABS
2
19-18-2
1
ABS
3
M4x60
4
Iron
4
This product has the following changes:
Code:
19-18
Code:
19-41
