Digital Panel Meter Enclosure
/
Non-standard
Product code: 2515A
[ Print version ]
[ Return ]
Size: 250x150x55 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
2515-1A
1
ABS
2
2515-2
1
ABS
3
1610-3
2
ABS
4
ST3x18
4
Iron
5
This product has the following changes:
Code:
2515
Code:
2515B
[ Print version ]
[ Return ]
