Digital Panel Meter Enclosure
/
120x120
Product code: 1251-1
[ Print version ]
[ Return ]
Size: 120x120x120 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
1251-1A
1
ABS
2
1251-2
1
ABS
3
0001
2
Iron
4
This product has the following changes:
Code:
1251
Code:
1251C
