SANHE ENCLOSURE / Products / Digital Panel Meter Enclosure / 80x160 / 8154

Index / Products / Digital Panel Meter Enclosure / 80x160

Product code: 8154

[ Print version ]

Size: 80x160x200 mm

ProtectionClass: no

Battery: no

Windows: no

PDF Drawings:


Note:
	Material and color can be customized.
	For modification, there will be surcharge.
	Drawings from website is just for reference.
	Certificates for waterproof and ex-proof are not available.
	Making toolings cooperative, 50% tooling cost will be undertaken.

more pictures...

Assembly Parts List
Serial No.	Part No.	Part Name	Qty	Material	Surface Finish	Remarks
1	8154	Case	1	ABS	Texture Finish
2	8121	Panel	1	ABS	Texture Finish
3	8103	Rear Terminal Block	1	ABS	Texture Finish
4	0011	Bracket	2	ABS	Mill Finish
5	8101-1	Small Bracket	1	ABS	Mill Finish
6	8101	Bracket	1	ABS	Mill Finish
7
Optional Parts
Serial No.	Part No.	Part Name	Qty	Material	Surface Finish	Remarks
1
2
3
4
5
6
7
