Product code: FA56
[ Print version ]
[ Return ]
Size: 115x100x146 mm
ProtectionClass: IP65
Battery: no
Windows: no
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
