Index /  Products /  Metal Enclosure /  Al.Extrusion Cabinet
Product code: 17-54
[ Print version ] [ Return ]


  • Size: 258x102 mm
  • ProtectionClass: no
  • Battery: no
  • Windows: no
  • PDF Drawings:  Download
    		•
    Note:
  		• Material and color can be customized.
  		• For modification, there will be surcharge.
  		• Drawings from website is just for reference.
  		• Certificates for waterproof and ex-proof are not available.
  		• Making toolings cooperative, 50% tooling cost will be undertaken.
    more pictures...
    Assembly Parts List
    Serial No.
    Part No.
    Part Name
    Qty
    Material
    Surface Finish
    Remarks
    1 252A-01  Cover  1 Al  Powder Coating
    2 252B-02 Bottom 1 Al  Powder Coating
    3  252B-03 Front/Rear Panel   2 Al
    4    Handle  1 Al Powder Coating
    5  D4 Plastic Bezel 2 ABS  Texture Finish
    6    Rubber Stopper 4 Rubber
    7    M3*6.5 Self Tapping Screw 8 Steel
    8    M3*8B Screw  4  Steel
    9    Bracket  2  Steel Wire
    10    Plastic Foot 4  ABS  Texture Finish
    11
    Optional Parts
    Serial No.
    Part No.
    Part Name
    Qty
    		 Material
    Surface Finish
    Remarks
    1
    2

    This product has the following changes:
    Code: 17-4

    Code: 17-4B

    Code: 19-4
