Plastic Enclosure
/
Annunciator Enclosure
Product code: 30-5
[ Print version ]
[ Return ]
Old code: 1450
Size: 42x80x145 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Assembly Parts List
Serial No.
Part No.
Part Name
Qty
Material
Surface Finish
Remarks
1
14-1
1
ABS
Texture Finish
2
14-2
Mid-case
1
ABS
Texture Finish
3
14-3
Base Part
1
ABS
Mill Finish
4
14-4
Front Cover
1
ABS
Texture Finish
5
14-5
Transparent Cover
1
PC
Mill Finish
6
14-6
Bracket
2
ABS
Mill Finish
7
Optional Parts
Serial No.
Part No.
Part Name
Qty
Material
Surface Finish
Remarks
1
2
