Index /  Products /  Plastic Enclosure /  Non-standard Meter Enclosure
Product code: 28-262
[ Print version ] [ Return ]


  • Size: 351x154x113 mm
  • ProtectionClass: no
  • Battery: no
  • Windows: no
  • PDF Drawings:  Download
  • Note:
  • Material and color can be customized.
  • For modification, there will be surcharge.
  • Drawings from website is just for reference.
  • Certificates for waterproof and ex-proof are not available.
  • Making toolings cooperative, 50% tooling cost will be undertaken.
    more pictures...
    Standard accessories
    No. Part No. Part Name Qty Material Note
    1 28-262-1 1 PA6+GF-V0
    2 28-262-2 1 Aluminum
    3 28-262-3 1 Rubber
    4 28-262-4 2 Aluminum
    5 28-262-5 2 Rubber
    6 28-262-6 1 Aluminum
    7 28-262-7 1 Rubber
    8 28-262-8 1 PA6+GF-V0
    9 28-262-9 1 PA6+GF-V0
    10 28-262-10 1 PA6+GF-V0
    11 28-262-11 2 PA6+GF-V0
    12 28-262-12 2 PA6+GF-V0
    13 28-262-13 1 Brass
    14 28-262-14 1 Brass
    15 28-262-15 1 Brass
    16 28-262-16 1 Brass
    17 28-262-17 1 Brass
    18 28-262-18 1 Brass
    19 28-262-19 1 Brass
    20 28-262-20 1 Brass
    21 28-262-22 1 PA6+GF-V0
    22 28-262-23 1 Brass
    23 28-262-24 1 Brass
    24 28-262-25 1 Brass
    25 28-262-26 1 PA6+GF-V0
    26 28-262-27 1 PA6+GF-V0
    27 28-262-28 1 PA6+GF-V0
    28 28-262-29 1 PA6+GF-V0
    29 28-262-30 1 PA6+GF-V0
    30
