Plastic Enclosure
/
Display Enclosure
Product code: 27-40
[ Print version ]
[ Return ]
Size: 360x240x224 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
27-40-1
1
ABS
2
27-40-2
1
ABS
3
27-40-3
1
ABS
4
27-40-4
1
ABS
5
27-40-5
1
ABS
6
27-40-6
1
ABS
7
27-40-7
1
ABS
8
27-40-8
1
ABS
9
27-40-9
1
ABS
10
27-40-10
1
ABS
11
27-40-11
4
ABS
12
27-40-12
1
ABS
13
27-40-13
1
ABS
14
27-40-14
1
Iron
15
27-40-15
2
Iron
16
27-40-16
2
Iron
17
27-40-17
1
Iron
18
27-40-18
16
Iron
19
27-40-19
8
Brass
20
27-40-20
2
Iron
22
