Plastic Enclosure
/
Standard Din-rail Enclosure
Product code: 23-118
[ Print version ]
[ Return ]
Size: 70x36x58 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
23-118-1
1
PPO
2
23-118-2
1
PPO
3
23-118-3
1
POM
4
23-118-4
1
PC
5
23-104-4
1
PPO
6
Optional accessories
No.
Part No.
Part Name
Qty
Material
Note
1
SH152-5.08
17
Nylon6
2
