Plastic Enclosure
/
Industrial Control Enclosure
Product code: 22-115
[ Print version ]
[ Return ]
Size: 111x84x35 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
22-115-1
1
PC+ABS
2
22-115-2
1
PC+ABS
3
22-115-3
1
Iron
4
M5x20YZ
1
Iron
5
M5TD
1
Spring steel
6
M5.5DP
1
Iron
7
