Index /  Products /  Plastic Enclosure /  Hand-held Enclosure
Product code: 21-48
[ Print version ] [ Return ]


  • Old code: PC9
    		•
  • Size: 180x65x35 mm
  • ProtectionClass: no
  • Battery: no
  • Windows: no
  • PDF Drawings:  Download
    		•
    Note:
  		• Material and color can be customized.
  		• For modification, there will be surcharge.
  		• Drawings from website is just for reference.
  		• Certificates for waterproof and ex-proof are not available.
  		• Making toolings cooperative, 50% tooling cost will be undertaken.
    more pictures...

    Assembly Parts List

    serial No.
    parts No.
    Part Name
    Qty

    Material
    Surface Finish
    Remarks

    1

    PC9-1

    Top Cover

    1

    ABS
    Texture Finish



    2

    PC9-2

    Base

    1

    ABS
    Texture Finish



    3

    PC9-3

    Cover

    1

    ABS
    Texture Finish



    4

    PC9-3

    Bottom Panel

    1

    ABS
    Texture Finish



    5













    Optional parts

    serial No.
    parts No.
    Part Name
    Qty

    Material
    Surface
    Finish


    Remarks

    1













    2
