Plastic Enclosure
/
Hand-held Enclosure
Product code: 21-141
[ Print version ]
[ Return ]
Size: 180x98x37 mm
ProtectionClass: no
Battery: 6 x R6,AA
Windows: 3.3",68.4x50.4mm
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
21-141-1
1
ABS
2
21-141-2
1
ABS
3
21-141-3
1
ABS
4
21-141-4
2
ABS
5
21-141-5
2
ABS
6
21-141-6
1
ABS
7
21-141-7
2
ABS
8
21-141-8
2
ABS
9
21-141-9
1
PC
10
DCTP5Z
1
Brass
11
DCTP5F
1
Brass
12
DCTP5ZF
2
Brass
13
DCTP5ZF2
3
Brass
14
M3x16
6
Iron
15
