Plastic Enclosure
/
Wall-mounting Enclosure
Product code: 19-27D
[ Print version ]
[ Return ]
Size: 109x70x40 mm
ProtectionClass: no
Battery: 2 x R6,AA
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
20-36-2
1
ABS
2
19-27-1
1
ABS
3
20-46-1
1
ABS
4
20-46-2
1
ABS
5
[ Print version ]
[ Return ]
