Plastic Enclosure
/
Plastic Cabinet
Product code: 15-29D
[ Print version ]
[ Return ]
Old code: 83
Size: 252x151x201 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
83-1
1
ABS
2
83-2
1
ABS
3
83-3
2
ABS
4
83-4
1
ABS
5
83-5
2
ABS
6
83-6
1
Aluminum
7
XSB-01
2
ABS
8
XSB-02
2
ABS
9
X290-8
2
ABS
10
X290-7
2
Iron
11
M3x6
6
Iron
13
M3x20
6
Iron
14
M3x10
2
Iron
15
