Product code: 11-198
[ Print version ]
[ Return ]
Size: 340x213x143 mm
ProtectionClass: no
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
11-198-1
1
PC+GF
2
11-198-2
1
PC+GF
3
11-198-3
2
PC+GF
4
11-198-4
2
PC+GF
5
11-198-5
2
PC+GF
6
xiao3x23
2
Stainless Steel
7
xiao3x33
2
Stainless Steel
8
xiao4x51
2
Stainless Steel
9
Optional accessories
No.
Part No.
Part Name
Qty
Material
Note
1
11-198-6
1
Aluminum
2
11-70-6
1
ABS
3
