Product code: 11-65
[ Print version ]
[ Return ]
Size: 32x32x6 mm
ProtectionClass: IP65
Battery: no
Windows: no
PDF Drawings:
Download
Note:
Material and color can be customized.
For modification, there will be surcharge.
Drawings from website is just for reference.
Certificates for waterproof and ex-proof are not available.
Making toolings cooperative, 50% tooling cost will be undertaken.
more pictures...
Standard accessories
No.
Part No.
Part Name
Qty
Material
Note
1
11-65-1
2
ABS
2
11-65-2
1
ABS
3
11-65-3
4
Rubber
4
M3DP
4
Iron
5
PT3x8
4
Iron
6
[ Print version ]
[ Return ]
